BMW S 1000R 2018 User Manual

ing 1 points to higher figure on
scale.
To decrease damping: turn
adjusting screw with tool from
onboard tool kit so that mark-
ing 1 points to lower figure on
scale.
Rebound stage, basic
setting, front
Position 1 (comfortable setting
with rider 187 lbs (85 kg))
Position 3 (standard setting
with rider 187 lbs (85 kg))
Position 7 (sport-oriented set-
ting with rider 187 lbs (85 kg))
Factory settings at front
wheel
Use following specification data
to adjust to factory settings.
Factory settings for
jounce/rebound at front
Position 3
Adjusting rebound-stage
damping at rear wheel
without Dynamic Damping
Control (DDC)
OE
Park motorcycle, ensuring that
support surface is firm and
level.
Adjust rebound-stage damping
with adjusting screw 1.
To increase damping: turn ad-
justing screw with tool from
onboard tool kit so that mark-
ing 1 points to higher figure on
scale.
To decrease damping: turn
adjusting screw with tool from
onboard tool kit so that mark-
ing 1 points to lower figure on
scale.
Rebound stage, basic
setting, rear
Position 1 (comfortable setting
with rider 187 lbs (85 kg))
5
75
z Setting

BMW S 1000R 2018 Specifications

General

Torque	114 Nm at 9, 250 rpm
ABS	Standard
Traction Control	Standard
Power	165 hp (121 kW) at 11, 000 rpm
Transmission	6-speed constant mesh
Rear Suspension	Aluminum swing arm, adjustable compression and rebound damping
Front Brake	Dual 320mm discs, 4-piston calipers
Rear Brake	Single disc brake, diameter 220 mm, single-piston floating caliper
Seat Height	814 mm
Fuel Capacity	17.5 liters
Weight	205 kg (wet weight)
Front Suspension	Upside-down telescopic fork, adjustable compression and rebound damping
