BNC 670C - Page 91

Model 670C Berkeley Nucleonics Corp. 91 of 96
B7
DO1_P
DO 1_P
B8
DO1_N
DO 1_N
B9
GND
SMA Ground
C1
+5Vcc
NA
C2
+5Vcc
NA
C3
GND
SMA Ground
C4
D5_P
DO 5_P
C5
D5_N
DO 5_N
C6
GND
SMA Ground
C7
D2_P
DO 2_P
C8
D2_N
DO 2_N
C9
GND
SMA Ground
D1
SCL (RESERVED). Do not connect.
NA
D2
SDA (RESERVED). Do not connect.
NA
D3
GND
SMA Ground
D4
D4_P
DO 4_P
D5
D4_N
DO 4_N
D6
GND
SMA Ground
D7
D3_P
DO 3_P
D8
D3_N
DO 3_N
D9
GND
SMA Ground
