180 S650 Operation & Maintenance Manual
LUBRICATING THE LOADER (CONT’D)
Lubrication Locations (Cont’d)
Earlier Models
Figure 283
Later Models
Figure 284
8. Bob-Tach Wedge (Both Sides) (2) [Figure 283] or
[Figure 284].
Figure 285
9. Rear Control Link (Both Sides) (2) [Figure 285].
Figure 286
10. Front Control Link (Both Sides) (2) [Figure 286].
P-85487
8
P-31308A
8
P100012
9
P-90544A
10
