BLT421S Product Manual
7
4.1 Bus system
Hypcut
IPC
master
station
Slave Station
HyPanel
BCS210E
Power supply
220V AC
BLT421S cutting head installation
wiring diagram
Notice:
 The above wiring operations should only be performed by trained and
professional personnel.
 When the cutting head is connected to the BCS210E, the BCS210E must
be powered off.
