BLT421S Product Manual
1
1.Product Description
1.1 Product View
Product View (Structure and Interface Description)
1. Optical fiber interface; 9. Cooling water outlet;
2. 1
st
Upper protective window; 10. Cutting gas interface;
3. 2
nd
Upper protective window; 11. Nozzle cooling gas inlet;
4. Collimation unit; 12. Cooling water inlet;
5. Focusing unit; 13. Anti-collision screw;
6. 2
nd
Lower protective window; 14. Ceramic body lock ring;
7. 1
st
Lower protective window; 15. Ceramic Part;
8. Working indicator; 16. Nozzle
1
4
2
3
5
6
8
10
9
13
12
11
14
15
16
7
