Stimplus Technical Data
MIN TYP MAX
Operating Voltage 4.5V 6.0V 6.5V
Output Intensity (500 ohms) 0mA - 1.2mA
Output Waveform Asymmetrical Biphasic rectangular
Stimulation Pulse Rate 13 Hz 16 Hz 19Hz
Pulse Width - 0.15ms -
Low Battery Indication 4.1V - 4.9V
Battery Life (30 sec/cycle) 3800 cycles --
Power Source Powered by 2 Lithium 3 volt batteries (included)
Weight (grams) 43.5g
Dimensions 16.5cm x 3.7cm x 1.3cm (6 1/2” x 1 7/16” x 9/16”)
Classification This unit is fully compliant with EEC Directive
93/42/EEC, and is classified as internally powered
equipment, Type BF. It is intended for continuous
operation.
Explanation of Symbols BF Isolated applied part
Warning – refer to accompanying documents
(i.e. this user manual)
Storage Temperature Range -5˚C – 65˚C
Storage Relative Humidity Up to 80%
