body Power BCB5280 - Assembly STEP 5: Weight Rack Frame

BCB5280/PRO5000 Page 11
Assembly STEP 5
Attach Rear Cross Tube (#16) to the two Upright Frames (#09),
secure by using four Hex Bolts (#18), four Washers (#27) and four
Nylon Nuts (#24).
Hardware Required
RACK
#18 Hex Bolt (M10X70mm)
[4 Pieces]
#27 Washer (M10)
[4 Pieces]
#24 Nylon Nut (M10
)
[4 Pieces]
