The following parts list describes all of the parts illustrated on the exploded diagram on the following page.
some of these items are already pre-installed. Please use this page only as a reference guide for parts and hardware.
# Description # Description
01 Front Stabilizer 22 Hex Bolt (M8x40 mm)
02 Main Frame 23 Hex Bolt (M6x12 mm)
03 Rear Stabilizer 24 Nylon Nut (M10)
04 Seat Cushion Tube 25 Nylon Nut (M8)
05 Backrest Cushion Tube 26 Nylon Nut (M6)
06 Backrest Cushion Adjustment Tube 27 Washer (M10)
07 Seat Cushion 28 Washer (M8)
08 Backrest Cushion 29 Washer (M8)
09 Upright Frame 30 Hex Bolt (M8x20 mm)
10 Left Weight Rest 31 Pop-Pin
11 Right Weight Rest 32 End Cap (60x60 mm)
12 Olympic Weight Plate Bar 33 End Cap (50x75 mm)
13 Weight Plate Bar 34 End Cap (50x75 mm)
14 Left Weight Bar Safety Catch 35 End Cap (40x60 mm)
15 Right Weight Bar Safety Catch 36 End Cap (25x50 mm)
16 Rear Cross Tube 37 End Cap (25 mm)
17 Hex Bolt (M10x80 mm) 38 Foam
18 Hex Bolt (M10x70 mm) 39 Roller
19 Hex Bolt (M8x65 mm) 40 End Cap (25 mm)
20 Hex Bolt (M8x55 mm) 41 Quick clip
21 Hex Bolt (M8x15 mm)
