BUB350/BUB375 Page 11
Assembly STEP 7
Attach Seat Cushion (#08) to the Seat Cushion Tube (#04),
secure them together by using four Hex Bolts (#14) and four
Washers (#18).
Attach Backrest Cushion (#09) to the Backrest Cushion Tube
(#05), secure them together by using four Hex Bolts (#14)
and four Washers (#18).
Hardware Required
THE ASSEMBLY PROCESS IS NOW COMPLETE.
However, for your own safety, please make sure to read
this entire Owner’s Manual which includes safety
instructions and warnings, as well as any safety/warning
labels axed to the product before use.
For your safety , please visually and functionally inspect
and test the unit after assembly is complete.
#14
Hex Bolt (M8x16 mm)
[8 Pieces]
#18
Washer (Ø8.3xØ16)
[8 Pieces]
To Next Page
