body Power BUB350 - Assembly STEP 3

BUB350/BUB375 Page 7
Assembly STEP 3
Attach Backrest Cushion Tube (#05) to the Backrest Cushion
Adjust Bracket (#07), secure them together by using two Hex
Bolts (#11), two Washers (#18) and two Nylon Nuts (#16).
Hardware Required
#16
Nylon Nut (M8)
[2 Pieces]
#11
Carriage Bolt (M8x75 mm)
[2 Pieces]
#18
Washer (Ø8.3xØ16)
[2 Pieces]
