Be careful to assemble all components
in the sequence they are presented.
12
STEP
A. Attach Angled Support Frame (D) to Main Base Frame (A) using:
Two 40 (1/2” x 3 1/4” hex head bolt)
Four 73 (1/2” washer)
Two 70 (1/2” nylon lock nut)
B. Insert Convex End Cap (4) to the fr
ont of the Top Frame (E).
Attach T
op Frame (E) and Plate (67) to the Rear Vertical Frame (C) using:
T
wo 40 (1/2” x 3 1/4” hex head bolt)*
Three 73 (1/2” washer)
One 70 (1/2” nylon lock nut)
*NOTE:
One bolt (40) goes into an internally threaded nut inside T
op Frame (E).
C. Attach Top Frame (E) and Plate (68) to Angled Support Frame (D) using:
Two 43 (1/2” x 4 1/4” hex head bolt)
Four 73 (1/2” washer)
T
wo 70 (1/2” nylon lock nut)
D. Insert Convex End Cap (2) to the small horizontal ar
m on Angled Support Frame (D) as shown.
NOTE:
Finger tighten all har
dware in this step. Do Not
wrench tighten until end of step 3.
