Body Solid G6B - Hardware Diagrams

86
(shown in actual size)
G6B HARDWARE
mm
Inch
KEY #40 HEX HEAD BOLT 1/2” X 3 1/4” PARTIAL THREAD QTY. 12
KEY #41 HEX HEAD BOLT 1/2” X 3 1/2” PARTIAL THREAD QTY. 1
KEY #42 HEX HEAD BOLT 1/2” X 3 3/4” PARTIAL THREAD QTY. 3
KEY #43 HEX HEAD BOLT 1/2” X 4 1/4” PARTIAL THREAD QTY. 2
KEY #44 HEX HEAD BOLT 1/2” X 5 1/2” PARTIAL THREAD QTY. 1
KEY #60 HEX HEAD BOLT
5/16” X 1 1/2” FULL THREAD
QTY. 2
KEY #62 HEX HEAD BOLT
5/16” X 1 3/4” FULL THREAD
QTY. 2
KEY #61 ALLEN HEAD BOLT 5/16” X 3/4” FULL THREAD QTY. 4
