87
(shown in actual size)
G6B HARDWARE
mm
Inch
KEY #54 HEX HEAD BOLT 3/8” X 7 1/4” PARTIAL THREAD QTY. 2
KEY #55 CARRIAGE BOLT 3/8” X 2 3/4” PARTIAL THREAD QTY. 2
KEY #56 HEX HEAD BOLT 3/8” X 3 1/4” PARTIAL THREAD QTY. 2
KEY #53 HEX HEAD BOLT 3/8” X 3” PARTIAL THREAD QTY. 7
KEY #52 HEX HEAD BOLT 3/8” X 2 3/4” PARTIAL THREAD QTY. 4
KEY #57 HEX HEAD BOLT 3/8” X 2 1/2” PARTIAL THREAD QTY. 1
KEY #51 HEX HEAD BOLT 3/8” X 1 3/4” PARTIAL THREAD QTY. 22
KEY #50 HEX HEAD BOLT 3/8” X 1”
PARTIAL THREAD QTY. 8
KEY #58 SOCKET HEAD BOLT
3/8” X 2” FULL THREAD
QTY. 1
