STEP
15
Above shows STEP 15
assembled and completed
39
Selectoe Eod Top Bolt(52) must be threaded a
minumum of 1/2" into the Selector Rod (6),and Jam
Nut (54) tightened securely against spring lock
washer (53) to ensure proper connection.Check the
Jam Nut (54) once a week to make sure it is tight.
79
52
99
136
135
!
!
WARNING
6
135
54
53
6
1
/
2
"
(at least)
36
F
130
A7
A6
A5
A3
AA
A1
A2
A8
A4
Start at high pully station by
inserting the Metal Ball End here.
6
36
79
52
G
To Next Page
