STEP
21
51
Selector Eod Top Bolt(52) Must be threaded a
minumum of a 1/2" into the Selector Rod (6),
and Lock Nut (54) tightened securely to ensure
proper connection.
WARNING
!
!
NOTE 1
Before beginning final cable
adjustments,be sure that both of
these pulley housing nutt-up as
close as possible to the welded
stops on the frame pieces.
NOTE 2
Check lock nut
weekly to be
sure it is tight
and locked on
to the Selector
Eod.
(See page 61)
52
B.Rubber Stop(42)
Tighten
C
B
B
C
A
8
A
8
D
D
K
1
C
Selector Rod Top Bolt
To Next Page
