55
WARNING
!
!
Pay special attention to the plunger on this Pop Pin (48).
Always be sure that the plunger is fully engaged
into the hole
you select.Also,be sure that the spring in the Pop Pin (48)
operates freely.Failure to do so may reault in serious injury.
Pull Ball Head
Pop Pin(57)
Adjust
Seated Press
Arm(AC)
(Reverse view drawing)
top Ball Head
Pop Pin (56)
side Ball Head
Pop Pin(56)
Adjust
Upper Back
Pad(ZA)
2.
1.
Leg Extensions
Seat Pad(v)
Pull T-Shaped
Pop Pin(48)
Make sure Pop PIn(48) is fully
engahed
into selector hole,and then
turn clockwise to lock it in place.
3.
