Body Solid GDR24 - Assembly Step 1; Attach Base Frames to Side Frames; Attach Upright Frames to Side Frames; Attach Upright Frames to Top Cover

8
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. Wrench tighten ALL hardware at the end until the
last step. Some components may be pre-assembled.
1A. AttachoneBaseFrames(B)totwoSideframes(A)using:
4 - (#1) M10x70mm Hex Head Bolt
8 - (#4) M10 Flat Washer
4 - (#5) M10 Nylon Lock Nut
1B. AttachtwoUprightFrames(C)toSideFrames(A)using:
4 - (#2) M10x20mm Hex Head Bolt
4 - (#4) M10 Flat Washer
1C. AttachtwoUprightFrames(C)toTopCover(D)using:
2 - (#3) M10x95mm Hex Head Bolt
4 - (#4) M10 Flat Washer
2 - (#5) M10 Nylon Lock Nut
