Body Solid GDR34 - Assembly Instructions; Step 1: Initial Assembly

8
STEP
1
Be careful to assemble all components
in the sequence they are presented.
NOTE:
Finger tighten all hardware in this step. DO NOT wrench tighten until instructed.
Some components may be pre-assembled. Nylon lock nuts will not fully screw onto
bolts, they must be wrench tightened to fully go on.
1A. AttachDumbbellTray(B)totheLowestPositionof
 Uprights(A)using:
4 - (#1) M10x65mm Socket Head Cap screw
4 - (#2) M10 Nylon Lock Nut
2 - (C) Steel Bracket
1B. Insert4piecesofPlasticFlatFootCaps(#3)ontoUprights(A).
1C. Insert2piecesofPlasticFlatTopCaps(#4)ontoUprights(A).
