2
Ratchet
9/16Socket
3/4Socket
9/16CombinationWrench
3/4CombinationWrench
AdjustableWrench
RubberMallet
MetricAllenKeySet
Recommended
Tools
forAssembly
61
HEIGHT
83
50
ImportantNotesandTips:
1.Donottightenboltsuntilinstructed.
2.Twopeoplearerequiredforthesafeassemblyof
thisproduct.
3.Usesiliconelubricantontheweightstackguide
rodspriortoweightplateinstallation.
4.Carefullyinstallplasticcapsusingarubbermallet.
5.Letplasticsacclimatetoroomtemperaturebefore
youbeginassembly.
6.Whenmeasuringboltlengths,onlymeasurethe
shank.Seebelow.
i.e.3HexBolt
0
1/4
1/2
3/4
1
1/4
1/2
3/4
2
1/4
1/2
3/4
3
1/4
Shank
S
PECIFICATIONS
T
OOLS
N
EEDED
