BODYMAX CF800 - Page 16

Assembly Instructions
W12
3
4
N12
H12-18
H12-18
N12
W12
1
16
CF800
Step 2: Assembly of the Rails
1. Attach the right rail (3) to the base front (1) with two bolts (H12-18), four washers (W12) and
two nuts (N12).
2. Attach the left rail (4) to the base front (1) with two bolts (H12-18), four washers (W12 and two
nuts (N12).
