14
15
W8
A8-7
16
A8-7
W8
H8-12
W8
W8
H8-12
W8
7
6
8
14
15
W8
A8-7
16
A8-7
W8
H8-12
W8
W8
H8-12
W8
7
6
8
23
Step 9: Assembly of the Pads, Part 2
1. Attach the upper back pad (14) to the leg press footrest (7) with four bolts (A8-7) and four
washers (W8).
2. Attach the head support pad (15) to the carriage (6) with two bolts (A8-7) and two washers (W8).
3. Attach two shoulder pads (16) to the shoulder pad mount (8) with four bolts (H8-12) and four
washers (W8).
