BODYMAX CF800 - Page 22

11
12
4
N8
H8-5
W8
3
11
12
4
N8
H8-5
W8
3
22
CF800
Step 8: Assembly of the Safety Stoppers
1. Attach the right safety stopper (11) to the right rail (3) with one bolt (H8-5), two washers (W8)
and one nut (N8).
2. Attach the left safety stopper (12) to the left rail (4) with one bolt (H8-5), two washers (w8) and
one nut (N8).
