BODYMAX CTX5 - 7.2 Parts List

1 connection tube 1
2 upright frame left 1
3 upright frame right 1
4 bending tube left 1
5 bending tube right 1
6 upper connection tube 1
7 upper bending tube right 1
8 upper bending tube left 1
9 hexagon bolt M10*75 54
10 lock nut M10 103
11 washer Φ10 213
12 chin up bar 1
13 upper plate 4
14 pulley frame tube right 1
15 pulley frame tube left 1
16 upright tube 2
17 tube with hole right 1
18 tube with hole left 1
19 lower plate 4
20 sliding tube right 1
21 sliding tube leftf 1
22 foot tube cover 2
23 end tube 2
24 hexagon bolt M10*80 14
25 lower base 2
26 upper base 2
27 guide rod Φ25*1850 2
28 lock sleeve 2
29 sliding sleeve 2
30 rubber pad with groove Φ60*Φ26*45 2
31 safety hook right 1
46
CTX5
7.2 Parts List
No. Name Specication Qty.
