BODYMAX E80 - Part List

Part list:
Part no Description Drawing no. Specification Q'ty
1 Main frame 741J2-3-1000-J0 1
2 Front stabilizer 741J2-3-2100-J0 1
5 Oval base 741J2-6-2173-B0 50*100*100 2
6 Curved washer D22xD8.5x1.5T 55108-3-2215-FA D22xD8.5x1.5T 12
7 Spring washer D15.4xD8.2x2T 55108-2-1520-FA D15.4xD8.2x2T 22
8 Flat washer D25*D8.5*2T 55108-1-2520-FA D25*D8.5*2T 12
9 Allen bolt M8x1.25x20L 50308-5-0020-F0 M8x1.25x20L 26
10 Handlebar post 741J2-3-2000-J0 1
11L Supporting tube for left pedal 741J2-3-3810-J1 1
11R Supporting tube for right pedal 741J2-3-3811-J1 1
12L
Supporting tube for left movable
handlebar 741J2-3-3710-J0 1
12R
Supporting tube for right movable
handlebar 741J2-3-3711-J0 1
13 Bushing 58002-6-1057-00 D35*11L 4
14 Bolt 50108-2-0020-U0 M8x1.25x20 6
15 Mushroom cap D11/4’’*29L 553K0-1-0029-B3 D1 1/4"*29L 2
16L Upper foot Cover (Left) 70501-6-2481-B0 80*55*87 2
16R Upper foot Cover (Right) 70501-6-2480-B0 80*50*87 2
17 bolt M6*1*15L 50308-5-0040-F3 M8*1.25*40L 2
18 Cross bolt 52606-2-0015-N0 M6*1*15L 4
19 Rear stabilizer 741J2-3-2112-B70 1
20 Domed nut M8*1.25*15L 55208-6-2015-FA M8x1.25x15L 2
21L Left pedal 58029-6-1138-B0 399.6*183.6*69.7 1
21R Right pedal 58029-6-1139-B0 399.6*183.6*69.7 1
22 Sliding beam guider 741J2-6-5171-00 R21*596*1.5T 2
23 Flat washer D22*D10*2T 55110-1-2220-NA D22*D10*2T 1
24 Anti-loosen nut 3/8"-26UNFx6.5T 18600-6-3175-N1 3/8"-26UNFx6.5T 2
25 Motor 180B2-6-2571-00 M8 1
26 C-clip D22.5*D18.5*1.2T 55519-1-2312-DA D22.5*D18.5*1.2T 2
27 Adjustable round wheel 709S0-6-2174-B0 D59*M10*40L 6
28 Bolt nut 55210-2-2008-NA M10*1.5*8T 6
29 Upper computer cable 73102-6-2572-00 800L 1
30 Lower computer cable 738A2-6-2573-00 800L 1
31 Round cap 55340-3-4080-B8 40*80*40L 4
32L Bracket for left pedal 741J2-3-6000-J1 1
32R Bracket for right pedal 741J2-3-6025-J1 1
33 Crank 739G0-3-2903-00 1
