PRE-ASSEMBLY CHECK LIST
NO:45 NO.14L/R
NO:11L/R NO:3 NO:53 NO:35 NO:82
NO:1 NO:9 NO:54
NO:20 NO:24 NO:55 NO:13 NO:8L/R
PART NO. DESCRIPTION Q’TY
1 Main frame 1
3 Roller Wheel 2
8L/R Front Post Floor Cap ( L/R ) 1/1
9 Middle support tube 1
11L/R Rowing Bar Holder ( L/R ) 1/1
13 Socket Head Allen Bolt 4
14L/R Pedal ( L/R ) 1/1
20
Computer support tube
1
24 Computer 1
35 Lock Pin 1
45 Rowing Rail 1
53 Seat 1
54 Rear support 1
55 Rear Leverage Knob 2
82 Adaptor 1
User manual 1
Hardware parts 1
