Boeing 747 - Page 62

DIAGONAL
BRACE
SIDE
BRACE
UPPER
LINK
FAIRING
FWD
A-A
ENGINE NACELLE
AND STRUT
3
3
2
4 4
TRANSDUCER
TRANSDUCER
GUIDE
1
ARE REMOVED FOR THE INSPECTION
INSPECTION
AREA
AREAS WHERE CRACKS HAVE OCCURRED
FUSE PIN INSPECTION SURFACES
3
4
2
1
A
A
INBOARD AND OUTBOARD INSERTS (NOT SHOWN)
_____ NOTES:
2131046 S0000459177_V1
Inspection Area on Strut
Figure 1
747
NONDESTRUCTIVE TEST MANUAL
PART 4 54-30-08
Page 6
Nov 15/2015D6-7170
