4. Operation
4.1 Controls and Indicator Lamps (see Figure below)
The power switch controls power to the unit.
The temperature display shows the chamber temperature in degrees Celsius.
The heater lamp indicated when the heater is operating.
The temperature adjust knob is used to control the chamber temperature.
Temperature
Adjust Knob
Power
Switch
OI
Heater
Lamp
Temperature
Display
SHELF INSTALLATION DIAGRAM
SHELF
BRACKET
INNER WALL
STEP #1
STEP #3
SHELF
STEP #2
90°
INNER
WALL
INNER
WALL
WALL
INNER
