18 Version 1 Oct 2009
SYSTEM SPECIFICATIONS
Unit: AD Oracle
Capacity: 380 m³/hr (224cfm)
Size: height 980mm x depth 430mm x width 430mm
(height 38.6“x depth 16.9“x width 16.9“)
Weight: 75Kg (165 lbs)
Exhauster: Centrifugal Fan
Output: 1.1kw
Electrical supply: 115 - 230v 1ph 50Hz / 60Hz
FLC: 12.5A
Noise level: Below 60dB (A)
(At Normal operating speed)
Filters: Pre filter Surface area 12.0 m²
Efficiency F8 85% @ 0.8µ
Combined:
HEPA filter Efficiency H13 99.997% @ 0.3µ
Surface Area 3.0m
2
Gas filter Activated Carbon 15kg
Environmental Operating Range
Temperature +5°C to +40°C
Humidity Max 80 % RH up to 31°C
To Max 50% RH at 40°C
