7 Version 1 Oct 2009
Extractor Overview
The AD range provides extraction and filtration of the fume generated by laser
marking, cutting, etching or engraving. The units are of robust design and feature
ease of use with minimal maintenance. The main components are shown in Fig. 5.
Fig. 5
1. Unit / Filter Condition Display – Auto Flow Control
2. On / Off Switch
3. Power Cable
4. Signal / Interface Cable to Laser
5. Filter Housing Cam Latch
6. Door Hinge
7. Hose Inlet Connection
8. Extracted Air Outlet
9. Motor Cooling In/Out
