BOGE Operating instructions for C 10 L...C 20 L series screw compressors Page 41
Maintenance 5.3 Regular maintenance work
Close ball valve at the compressed air outlet.
Open safety sound insulation hood.
Vent the compressor (as described in the beginning of the chapter).
Wait approx. 3 minutes to permit the oil to settle.
Fig. 5.5: Changing the oil separators
Open ball valve at the compressed air outlet.
Switch on the compressor and heat up to operating temperature.
Check the oil separators for leaks once again (procedure as described
above).
Check the oil separators for leaks and tighten by hand, if necessary.
Caution: Risk of injury!
Danger of burning due to hot oil!
Always wear safety gloves!
Remove cladding from
the service side.
Unscrew soiled oil sepa-
rators (4) by hand or use
a strap wrench, turning
counterclockwise.
Catch the draining oil and
dispose of properly ac
-
cording to environmental
regulations.
Lightly oil the sealing
rings of the new oil sepa
-
rator.
Screw in new oil separa-
tors (4) by hand, turning
clockwise.
Attention!
Do not use tools to screw in the new oil separators!
You might damage the oil separators or their sealing rings.
A hand tight seating of the oil filter is sufficient.
Caution: Risk of injury!
Press Emergency Stop button, open mains disconnection device and secure
against unintentional switch on by means of a padlock.
