Specifications
12
Power Output (RMS): V35
V60 V100 V150 V250
Rated: 35W 60W 100W 150W 250W
Typical @ 1 kHz:* 45W 85W 140W 200W 340W
Frequency Response
Transformer: 45 Hz to 20 kHz; +0/-2 dB
Direct: 20 Hz to 20 kHz; +0/-1 dB
Distortion
Transformer: < 0.5%**
Direct: < 0.1%** (.05 typical @ 1 kHz)
Signal-to-Noise
†
Fundamental: -94 dB
With SAX1R Module: -70 dB
With MIC1S Module: -60 dB
With TEL1S Module: -70 dB
Tone Controls
Bass Frequency: @100 Hz (+/- 10 dB minimum)
Treble Frequency: @10 kHz (+/- 10 dB minimum)
Low Cut Frequency: @125 Hz (-6 dB/octave)
Sensitivity: 0.4V (at backplane connector)
Output Regulation: 2 dB or better, no load to full load
Output Impedance
Transformer-Coupled: 70V, 25V, 8 ohms (bal or unbal)
Direct Coupled: 4 ohms (minimum)
Thermal Emissions (BTU/hr.): V35
V60 V100 V150 V250
174.2 204.9 495.2 696.7 911.9
Inserts
Insert "OUT" Level: 1VRMS (@FRP)
Insert "OUT" Impedance: 50 ohms maximum
Insert "IN" Sensitivity: 1VRMS
Insert "IN" Impedance: 10k ohms minimum
Bridging In/Out
Bus Level: 250 mVRMS (@FRP)
Bus Impedance: 10k ohms maximum
Pre-EQ Output
Output Level: 4VRMS (@FRP)
Output Impedance: 50 ohms maximum
AC Power Receptacle: 500 watts maximum power, unswitched
AC Voltage: 120V AC, 60 Hz
AC Current: V35
V60 V100 V150 V250
0.6A 1.3A 2.0A 3.5A 5.5A
Product Weight (lb.): V35
V60 V100 V150 V250
22 26 28 31 32
Dimensions: 17-1/4" W x 3-7/8" H x 14-3/4" D (all models)
* Typical, @1 kHz/0.1% THD/4-ohm direct ** THD+N, Maximum, Full bandwidth @ FRP
† Referenced to FRP output level, 20 Hz to 20 kHz bandwidth limited
