The amplifier shall be a Bogen Wall-Mount Power Vector
Amplifier, Model WV100,WV150 or WV250.The amplifier
shall be compatible with both high- (70/25V) and low- (4/8-
ohm) impedance speakers, with the capability of 100, 150,
or 250 watts, respectively.
The amplifier shall provide 8 module bays for plug-in input
modules with two of the bays also capable of handling plug-
in signal processing output modules.There shall be 4 levels
of priority between modules.
Each of the 8 module bays shall have an associated inde-
pendent volume control. Each independent volume control
shall have a signal/clip LED to indicate if a clipping condition
is occuring at the module’s output. Each amplifier shall also
include detented bass and treble controls, as well as a
motorized master volume control, which can be remotely
operated using the RVCP accessory (sold separately).
The amplifier shall include an adjustable output level limiter
with indicator LED. A tape output jack shall be available on
the front panel and an optional front panel input combo
jack with 1/4" stereo phone and female XLR capabilities
may be installed.
Screw terminals shall be provided for invoking a master
mute function that will interrupt all audio from the mixer
section of the amplifier.
An 11 -segment LED output level meter will register either
the average or peak level of the amplifier’s output level,
determined by an Average/Peak switch. Each amplifier shall
have a Tone Control Bypass switch and a Low-Cut Filter
switch located on the rear of the amplifier in module bay 6.
A switch will permit the selection of transformer-coupled
output or direct output for speaker runs. Master mute and
remote volume control functions are controlled using a
screw terminal.
The amplifier shall be flush-mounted or surface-mounted
into a wall using either a BBF or BBS back box (sold sepa-
rately).A front cover door shall be required (WMAD sold
separately). Each model shall measure 14-1/8" W x 21" H.
The WV100 shall weigh 27 lb.; the WV150, 29 lb.; and the
WV250, 28 lb.
Architect and
Engineer
Specifications
50 Spring Street, Ramsey, New Jersey 07446, U.S.A.
201-934-8500 FAX: 201-934-9832
Web Site: www.bogen.com
Technical
Specifications
Power Output (RMS)
WV100: 100W (140W Typical, @1 kHz/0.1%/4Ω)
WV150: 150W (200W Typical, @1 kHz/0.1%/4Ω)
WV250: 250W (340W Typical, @1 kHz/0.1%/4Ω)
Frequency Response
Transformer: 45-20 kHz; 0/-2 dB @ FRP
Direct: 20-20 kHz; 0/-1 dB @ FRP
Distortion
Transformer: 0.5% THD+N, Maximum,
Full-rated bandwidth @ FRP
Direct: 0.1% THD+N, Maximum,
Full-rated bandwidth @ FRP
Signal-to-Noise
Fundamental: -94 dB*
With Aux Module: -70 dB*
With Mic Module: -60 dB*
With Tel Module: -70 dB*
Tone Controls
Bass Frequency: 100 Hz (+/- 10 dB minimum)
Treble Frequency: 10 kHz (+/- 10 dB minimum)
Low Cut Frequency: 125 Hz @ -6 dB/octave
Sensitivity: 0.4V (at backplane connector)
Output Regulation: 2 dB or better no load to full load
Output Impedance
Transformer-Coupled: 70V, 25V, 8 ohms; balanced or unbalanced
Direct Coupled: 4 ohms unbalanced
Tape Out
Output Level: 4 VRMS @ FRP
Output Impedance: 50 ohms maximum
Overload Protection: Electronic overload protection
(auto reset)
Thermal Protection: Thermistor attached to heat sink
Line Fusing: Resettable circuit breaker
Cooling: Thermally controlled 3-speed fan
Power Consumption: WV100: 2.0A @ 120V AC, 60 Hz
WV150: 3.5A @ 120V AC, 60 Hz
WV250: 5.5A @ 120V AC, 60 Hz
Dimensions:
WV100/150/250: 14-1/8" W x 21" H
BBF: 14-1/2" W x 24-3/4" H x 3-7/8" D
BBS: 16-1/4" W x 26-3/4" H x 3-7/8" D
WMAD: 16-1/4" W x 26-3/4" H x 1" D
Product Weight:
WV100: 27 lb.
WV150: 29 lb.
WV250: 28 lb.
BBF: 14 lb.
BBS: 18 lb.
WMAD: 11 lb.
* Referenced to full-rated power (FRP) output level, 20-20 kHz bandwidth limited.
All specifications subject to change without notice.
