Bohn BHA - Page 10

10
50 Hz Performance
Model
Capacity
BTUH/watts
6°C TD
-29°C SST
Fan Data
Standard Motor Data Defrost Heaters
HP
Total Amps
Watts
Total Amps
CFM/m
3
h No.
Dia.
in./mm
Air Throw ft./m 380/1/50
380
/3/50
380
/3/50
Standard
w/
Collar
Wired
1-Phase
Wired
3-Phase
BHE Models 6 Fins Per Inch
BHE450 41,400 12,100 8,100 23,400 2 24 610 60 18 80 24 1/2* 3.4 - 2.6 6,760 11.5
BHE550 50,600 14,800 8,100 23,400 2 24 610 60 18 80 24 1/2* 3.4 - 2.6 6,760 11.5
BHE640 58,900 17,300 11,300 32,700 3 24 610 60 18 80 24 1/2* - 3.0 3.9 8,800 15.0
BHE740 68,100 19,900 11,300 32,700 3 24 610 60 18 80 24 1/2* - 3.0 3.9 8,800 15.0
BHE810 74,500 21,800 15,100 43,800 4 24 610 60 18 80 24 1/2* - 4.7 5.2 11,640 20.1
BHE950 87,400 25,600 15,100 43,800 4 24 610 60 18 80 24 1/2* - 4.7 5.2 11,640 20.1
BHE1020 93,800 27,500 18,600 53,900 3 30 762 90 27 100 30 1 - - 6.9 14,600 26.5
BHE1200 110,400 32,300 18,600 53,900 3 30 762 90 27 100 30 1 - - 6.9 14,600 26.5
BHE1390 127,900 37,500 21,900 63,200 3 30 762 90 27 100 30 1-1/2 - - 9.9 14,600 26.5
BHE1650 151,800 44,500 23,900 69,000 3 30 762 110 34 130 40 1-1/2 - - 10.5 22,930 39.2
BHE2120 195,000 57,100 31,900 92,100 4 30 762 110 34 130 40 1-1/2 - - 14.0 33,850 57.8
BHL Models 4 Fins Per Inch
BHL400 36,800 10,800 8,500 24,500 2 24 610 60 18 80 24 1/2* 3.4 - 2.6 6,760 11.5
BHL480 44,200 12,900 8,500 24,500 2 24 610 60 18 80 24 1/2* 3.4 - 2.6 6,760 11.5
BHL560 51,500 15,100 11,900 34,300 3 24 610 60 18 80 24 1/2* - 3.0 3.9 8,800 15.0
BHL650 59,800 17,500 11,900 34,300 3 24 610 60 18 80 24 1/2* - 3.0 3.9 8,800 15.0
BHL710 65,300 19,100 15,900 45,700 4 24 610 60 18 80 24 1/2* - 4.7 5.2 11,640 20.1
BHL840 77,300 22,600 15,900 45,700 4 24 610 60 18 80 24 1/2* - 4.7 5.2 11,640 20.1
BHL890 81,900 24,000 19,500 56,200 3 30 762 90 27 100 30 1 - - 6.9 14,600 26.5
BHL1050 96,600 28,300 19,500 56,200 3 30 762 90 27 100 30 1 - - 6.9 14,600 26.5
BHL1220 112,200 32,900 22,700 65,500 3 30 762 90 27 100 30 1-1/2 - - 9.9 14,600 26.5
BHL1440 132,500 38,800 24,900 71,800 3 30 762 110 34 130 40 1-1/2 - - 10.5 22,930 39.2
BHL1860 171,100 50,100 33,100 95,800 4 30 762 110 34 130 40 1-1/2 - - 14.0 33,850 57.8
Table 7. Models BHE/BHL 50 Hz Electric Defrost
* 380/3/50 motors are 3/4 HP
Notes: TD = Temperature Dierence = (Room temperature - saturated suction temperature)
Saturated Suction Temperature °F +20 -10 -20 -30 -40
Saturated Suction Temperature °C -7 -23 -29 -34 -40
Multiply Capacity By 1.15 1.04 1.00 0.90 0.80
Capacity Correction Factors for Electric and Hot Gas Defrost Units
