Bohn BHA - 50 Hz Performance

9
50 Hz Performance
* 380/3/50 motors are 3/4 HP
Notes: TD = Temperature Dierence = (Room temperature - saturated suction temperature)
Table 6. Model BHA 50 Hz Air Defrost
Model
Capacity
BTUH/watts
6°C TD
-4°C SST
Fan Data
Standard Motor Data
HP
Total Amps
CFM/m
3
h No.
Dia.
in./mm
Air Throw ft./
m 220/1/50 380/1/50
380
/3/50
Standard w/ Collar
Wired
1-Phase
Wired
1-Phase
Wired
3-Phase
BHA Models 6 Fins Per Inch
BHA520 47,800 14,000 8,100 23,400 2 24 610 60 18 80 24 1/2* 6.4 3.4 - 2.6
BHA630 58,000 17,000 8,100 23,400 2 24 610 60 18 80 24 1/2* 6.4 3.4 - 2.6
BHA750 69,000 20,200 11,300 32,700 3 24 610 60 18 80 24 1/2* 9.6 - 3.0 3.9
BHA850 78,200 22,900 11,300 32,700 3 24 610 60 18 80 24 1/2* 9.6 - 3.0 3.9
BHA930 85,600 25,100 15,100 43,800 4 24 610 60 18 80 24 1/2* 12.8 - 4.7 5.2
BHA1100 101,200 29,600 15,100 43,800 4 24 610 60 18 80 24 1/2* 12.8 - 4.7 5.2
BHA1170 107,600 31,500 18,600 53,900 3 30 762 90 27 100 30 1 - - - 6.9
BHA1400 128,800 37,700 18,600 53,900 3 30 762 90 27 100 30 1 - - - 6.9
BHA1610 148,100 43,400 21,900 63,200 3 30 762 90 27 100 30 1-1/2 - - - 9.9
BHA1900 174,800 51,200 23,900 69,000 3 30 762 110 34 130 40 1-1/2 - - - 10.5
BHA2200 202,400 59,300 27,400 79,100 4 30 762 110 34 130 40 1-1/2 - - - 13.2
BHA2440 224,500 65,800 31,900 92,100 4 30 762 110 34 130 40 1-1/2 - - - 14.0
BHA Models 8 Fins Per Inch
BHA2160 198,700 58,200 23,400 67,500 3 30 762 110 34 130 40 1-1/2 - - - 10.5
BHA2500 230,000 67,400 26,700 77,000 4 30 762 110 34 130 40 1-1/2 - - - 13.2
BHA2780 255,800 74,900 31,200 90,000 4 30 762 110 34 130 40 1-1/2 - - - 14.0
