Bohn BHA - Physical Specifications

16
Physical Specications
Model
No.
of
Fans
Connections (in.)
Approx.
Net Wt.
(lbs./kg.)
Coil Inlet
ODF
Suction
ODF
External
Equalizer
ODF
Drain
FPT
Hot Gas
Side Port
Hot Gas Drain
Pan Ref. Conn.
(when supplied)
BHG Models 6 Fins Per Inch
BHG450 2 1-1/8 1-5/8 1/4 1-1/4 5/8 1-1/8 280 130
BHG550 2 1-1/8 1-5/8 1/4 1-1/4 5/8 1-1/8 310 140
BHG640 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 405 180
BHG740 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 445 200
BHG810 4 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 535 240
BHG950 4 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 585 270
BHG1020 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-3/8 753 340
BHG1200 3 1-5/8 2-1/8 1/4 1-1/4 1-1/8 1-3/8 815 370
BHG1390 3 1-3/8 (2 conns) 2-1/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-3/8 865 390
BHG1650 3 1-3/8 (2 conns) 2-5/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-5/8* 1,175 530
BHG2120 4 1-3/8 (2 conns) 2-5/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-5/8* 1,620 730
BHF Models 4 Fins Per Inch
BHF400 2 1-1/8 1-5/8 1/4 1-1/4 5/8 1-1/8 277 130
BHF480 2 1-1/8 1-5/8 1/4 1-1/4 5/8 1-1/8 306 140
BHF560 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 400 180
BHF650 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 440 200
BHF710 4 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 528 240
BHF840 4 1-3/8 2-1/8 1/4 1-1/4 7/8 1-1/8 578 260
BHF890 3 1-3/8 2-1/8 1/4 1-1/4 7/8 1-3/8 744 340
BHF1050 3 1-5/8 2-1/8 1/4 1-1/4 1-1/8 1-3/8 805 370
BHF1220 3 1-3/8 (2 conns) 2-1/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-3/8 854 390
BHF1440 3 1-3/8 (2 conns) 2-5/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-5/8* 1,160 530
BHF1860 4 1-3/8 (2 conns) 2-5/8 (2 conns) 1/4 (2 conns) 1-1/4 7/8 (2 conns) 1-5/8* 1,600 730
Table 13. Model BHG/BHF Hot Gas Defrost
* Opposite end connections
