Bohn BHA - Page 12

12
50 Hz Performance
Notes: High CFM models can handle external static pressure up to 1/2” of water
High CFM models are designed for operation below 15°F SST
CFM is at 0.0 external static pressure
Notes: TD = Temperature Dierence = (Room temperature - saturated suction temperature)
Table 9. Models BHE/BHL 50 Hz Electric Defrost High CFM
Model
Capacity
BTUH/watts
6°C TD
-29°C SST
Fan Data
Standard Motor Data Defrost Heaters
HP
Total Amps
Watts
Total Amps
CFM/m
3
h No.
Dia.
in./mm
Air Throw ft./m
380
/3/50
380/3/50
Standard w/ Collar
BHE Models 6 Fins Per Inch
BHE450*V 45,500 13,300 10,200 17,300 2 24 610 80 24 90 27 2 6.0 6,760 11.5
BHE550*V 55,700 16,300 10,200 17,300 2 24 610 80 24 90 27 2 6.0 6,760 11.5
BHE640*V 64,800 19,000 14,300 24,300 3 24 610 80 24 90 27 2 9.0 8,800 15.0
BHE740*V 74,900 21,900 14,300 24,300 3 24 610 80 24 90 27 2 9.0 8,800 15.0
BHE810*V 82,000 24,000 19,100 32,500 4 24 610 80 24 90 27 2 12.0 11,640 20.1
BHE950*V 95,700 28,000 19,100 32,500 4 24 610 80 24 90 27 2 12.0 11,640 20.1
BHE1020*V 98,500 28,800 21,000 35,700 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHE1200*V 115,900 33,900 21,000 35,700 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHE1390*V 134,300 39,300 24,500 41,700 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHE1650*V 160,100 46,900 26,700 45,400 3 30 762 120 37 140 43 3 12.3 22,930 39.2
BHE2120*V 205,200 60,100 35,700 60,700 4 30 762 120 37 140 43 3 16.4 33,850 57.8
BHL Models 4 Fins Per Inch
BHL400*V 38,600 11,300 11,000 18,700 2 24 610 80 24 90 27 2 6.0 6,760 11.5
BHL480*V 46,400 13,600 11,000 18,700 2 24 610 80 24 90 27 2 6.0 6,760 11.5
BHL560*V 54,100 15,800 15,300 26,000 3 24 610 80 24 90 27 2 9.0 8,800 15.0
BHL650*V 62,800 18,400 15,300 26,000 3 24 610 80 24 90 27 2 9.0 8,800 15.0
BHL710*V 68,600 20,100 20,400 34,700 4 24 610 80 24 90 27 2 12.0 11,640 20.1
BHL840*V 81,100 23,800 20,400 34,700 4 24 610 80 24 90 27 2 12.0 11,640 20.1
BHL890*V 83,900 24,600 21,400 36,400 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHL1050*V 99,000 29,000 21,400 36,400 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHL1220*V 115,000 33,700 29,500 50,200 3 30 762 100 30 120 37 3 12.3 14,600 26.5
BHL1440*V 135,200 39,600 27,600 46,900 3 30 762 120 37 140 43 3 12.3 22,930 39.2
BHL1860*V 174,800 51,200 36,700 62,400 4 30 762 120 37 140 43 3 16.4 33,850 57.8
Saturated Suction Temperature °F +20 -10 -20 -30 -40
Saturated Suction Temperature °C -7 -23 -29 -34 -40
Multiply Capacity By 1.15 1.04 1.00 0.90 0.80
Capacity Correction Factors for Electric and Hot Gas Defrost Units
