BOJ CCM-800 - Machine Components and Indicators; Overview of Machine Parts; Understanding Indicator Lights

Adjustable dispenser spout (2 positions)
Denition of lighting
Name Status Function Action
Indicator
Blink in rst use
Refer to “ushing out the machine
and internal piping”
Light steady: water tank is empty
Fill up water tank, open the handle
and then press any button to ll
the internal circuit
Light steady Stand-by
J
K
Short espresso-button
Normal espresso button Lungo espresso button
C
A
B
E
D
G
H
I
F
A. Handle
B. Buttons
C. Dispenser
D. Used capsule container
E. Drip tray set
F. Drip tray (removable)
G. Drip try cover
H. Main switch
I. Wall
J. Water tank cover
K. Water tank (removable)
