LITE
What do you need?
Set-Up Guide
Power source
BOLT LITE requires a single-phase connection with earthing.
Locate nearest power source to avoid laying down of huge network of cables.
Find out whether the power source identified above has spare load of at least 3.3 Kw.
Once power source is identified, locate the wall on which device can be mounted.
Mounting
Take the device out of the box
Check out if the box contains all the materials as per the list attached
Place the device against the wall and mark the screw points for drilling
Mount and secure the device firmly with screws
Connection
Check the cable coming out of the BOLT device – three wires namely red, black, and
green/yellow (Color could be different).
Red stands for phase, black for neutral and green/yellow for earthing.
Connect the above cable to the power source cables.
Properly insulate the connections.
