BOMCO F-1600 - Use of New Mud Pump; Technical Specification and Performance Parameter

3
BOMCO F-1300/1600 is key equipment matched to drilling rig for petroleum well. It is used for
transporting drilling fluid to well bottom by high-pressure manifolds of circulating system in order to
cool off the drill bit, flush the well bottom, crush and take out the rock, and balance the formation
pressure.
The design and manufacture of F series mud pump is in compliance with API Spec. 7K. The module
size of fluid end conforms to API Spec. 7.
1. Use of new mud pump
1.1 Technical Specification and Performance Parameter
1.1.1. Technical Specification
Model
F－1300 F－1600
Type Triplex single acting piston pump
Max. Liner size mm 180 180
Rated Power kW 960 1180
Rated stroke spm 120 120
Stroke length mm 305 305
Gear ratio 4.206 4.206
Valve pots API 7
#
API 7
#
Weight kg 24572 24971
1.1.2. Performance data
Performance data of F-1300/1600 Mud Pump data sees table 1A. When imperial system liner is
adopted, the performance data sees table 1B.
1.1.3. Overall Dimension
Overall dimension of F-1300/1600 Mud Pump sees Fig.1.
Table 1A Performance data of F-1300/1600 Mud Pump
Liner Diameter, mm & Rating pressure, MPa（Psi）
180 170 160 150 140 130
F-1300 18.7 2720 21.0 3050 23.7 3440 27.0 3915 31.0 4495 34.5 5000
F-1600 23.1 3345 25.9 3750 29.2 4235 33.2 4820 34.5 5000 34.5 5000
Rating power
F-1300 F-1600
Stroke/minute
kW HP kW HP
Displacement L/S (GPM)
130 1050 1408 1293 1733
50.42
(799)
44.97
(713)
39.83
(631)
35.01
(555)
30.50
(483)
26.30
(417)
*120 969 1300 1193 1600
46.54
(737)
41.51
(658)
36.77
(583)
32.32
(512)
28.15
(446)
24.27
(385)
110 889 1192 1094 1467
42.66
(676)
38.05
(603)
33.71
(534)
29.62
(469)
25.81
(409)
22.25
(352)
100 808 1083 994 1333
38.78
(614)
34.59
(548)
30.64
(485)
26.93
(427)
23.46
(372)
20.23
(320)
