BONANZA BEECHCRAFT - Nose Gear Setup; 10-Nose Gear Assembly and Installation; Electric Retract Landing Gear Notes

2- Insert “Z” bend of steering linkage inside the hole of front landing gear
Steering arm.
3- Position the steering arm inside the front landing gear mount already
Attached to the firewall.
5- Screw steering arm on the leg.
Nose gear mount
3x20mm screw...4
Steering arm...1
..............1
IN CASE OF ELECTRIC RETRACT LANDING GEAR USING
Nose gear pushrod
Steering horn
10-Nose gear
(Electric retract landing gear and Struts must purchase separately)
1
2
3
3mm nut, washer...4
1- Route the steering linkage into the fuselage and through the
fire-wall.
4- Slide in the front gear leg with the flat to back through the bearing and
steering arm.
3
Flat
Landing gear steering arm
2
Steering linkage
4
5
