Bond 52661 - Installing Feet and Wheel Assembly; Connecting Base Components; Placing Grate and Firepot

6
ASSEMBLY INSTRUCTIONS
3. Screw in 4 pcs feet (L) to bottom base
(K), then attach wheel assembly (J) to
bottom base (K) using 2pcs M6x 20
screws (CC) and 2 pcs M6 nuts (DD).
K
DD
J
CC
L
4. Attach bottom base (K) to heater base
(H) using 4 pcs M6x 40 screws (EE).
EE
K
H
5. Place the grate (F) into repot (G), then
place repot into heater body assembly
(E).
2
1
F
G
E
3
