7
en
OVERVIEW AND PART NAMES
1 On/Off, output level
2 Fan
3 Cover / air inlet
4 Fragrance container
5 Drum
6 Evaporator mat
7 Air outlet
8 Power cable
9 Water base
1
2
3 4 5 6
87 9
