Maximum permissible tilt during
handling: 15°
15°
1
5
°
MAX
Lift manually
(weight £ 15 kg)
M
Lift as per diagram A
A
Lift as per diagram B
B
Snap hook
(use with rope)
Screw clamp
(use with harness)
Eyebolt (already fitted
to gear units VF130...VF250)
3
Open harness
with eyelets
2
Rope and hooks
1
Ring harness
VF 30
MVF 44 VFR 44
VF 49 VFR 49
VF 130 VFR 130
A-B A-B A-B
VF 150 VFR 150
VF 185 VFR 185
VF 210 VFR 210
VF 250 VFR 250
Reccomended:
solution A for positioning; solution B for positioning and handling.
