5. Charge the gear unit with oil or top it up with reference to the method in which gear units of the type co
-
vered by this manual are filled in the factory. The standard charge of synthetic life-time lubricant is as fol
-
lows:
C 05 C 11 C 21 C 31 C 35 C 41 C 51 C 61 C 70 C 80 C 90 C 100
A 10 A 20 A 30 A 41 A 50 A 60 A 70 A 80 A 90
F10F20F30F40F50F60F70F80F90
S10 S20 S30 S40 S50
VF 27 VF 30 VF 44 VF 49 VF 130 VF 150 VF 185 VF 210 VF 250
W 63 W 75 W 86 W 110
(A1)
Life-time lubrication.
Life-time lubrication with ATEX-specified unit only.
Cap/vent thread Pitch Tightening torque
[Nm]
1/8" 28 5
1/4" 19 7
3/8" 19 7
1/2" 14 14
3/4" 14 14
1" 11 25
Bolt size
Tightening torque [Nm]
+5% /-10%
Bolt class
8.8 10.9
M4 3 3.8
M5 5.9 8.0
M6 10.3 13.0
M8 25.5 32
M10 50 64
M12 87.3 110
M14 138.3 180
M16 210.9 275
M18 306 390
M20 432 540
M22 592 720
M24 744 930
M27 1100 1400
M30 1500 1850
(A0)
