BONFIGLIOLI C Series User Manual

36
Worm gear units, series W:
B3 B6 B7 B8 V5 V6 R
W63
i = 7, 10, 12, 15 0.31 0.31 0.31 0.31 0.31 0.31
0.15
i = 19, 24, 30, 38, 45, 64, 80, 100 0.38 0.38 0.38 0.38 0.38 0.38
W75
i = 7, 10, 15 0.48 0.48 0.48 0.48 0.48 0.48
0.25i = 30, 40 0.52 0.52 0.52 0.52 0.52 0.52
i = 20, 25, 50, 60, 80, 100 0.56 0.56 0.56 0.56 0.56 0.56
W86
i = 7, 10, 15 0.64 0.64 0.64 0.64 0.64 0.64
0.25i = 30 0.73 0.73 0.73 0.73 0.73 0.73
i = 20, 23, 40, 46, 56 ,64, 80, 100 0.90 0.90 0.90 0.90 0.90 0.90
B3 B6 B7 B8 V5 V6 R
W 110
P80…P132 - - 1.5 1.7 1.7 1.9 1.7 1.6
0.40
- M2 – M3 - 1.5 1.7 1.7 1.9 1.7 1.6
--
7 £ i £ 15 1.5 1.7 1.7 1.9 1.7 1.6
20 £ i £ 100 2.7 1.7 1.7 1.9 1.7 1.6
(A15)
oil
[l]
Single-stage helical gear units, series S:
PF
B3 B6 B7 B8 V5 V6 B5 B51 B52 B53 V1 V3
S101 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30 0.30
S201 0.45 0.45 0.45 0.45 0.45 0.45 0.45 0.45 0.45 0.45 0.45 0.45
S301 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70 0.70
S401 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6 1.6
S501 1.7 2.2 2.2 3.0 3.0 2.0 1.7 1.7 1.7 1.7 3.0 2.0
(A16)
oil
[l]
Life-time lubricated gear units.
Life-time lubricated gear units only in combination with ATEX variants.
Lubricant is not factory filled.
Life-time lubricated gear units.
Lubricant is not factory filled.
