bonitron M3452-U600CK6 - Figure 6-6: M3452 T10 Chassis Dimensional Outline Drawing

User’s Manual
59
Figure 6-6: M3452 T10 Chassis Dimensional Outline Drawing
10.12
257.05mm
19.18
487.17mm
23.00
584.20mm
13.44
141.38mm
5.91
150.11mm
13.44
341.38mm
10.19
27.00
685.0mm
30.59
776.99mm
