WARNING
WHAT’S INCLUDED
• LC-1X
• DC12V 2A 90~240VAC Power Supply
• User Manual
• 40” RGB LED Strip
• 25’ USB Type A to Type B Cable
SAFETY INSTRUCTIONS
• Do not operate this unit at temperatures above 113°F
• Only use the supplied power supply
• Make sure the power supply’s cord is not pinched or damaged in any way
• Make sure the power supply is plugged into an appropriate voltage source
• Before making any changes to the DIP switches, turn off the power by unplugging the unit
• If any defects with the unit are discovered, please contact an authorized service technician
for assistance
1.0 INTRODUCTION
1.1 Overview
The LC-1X is a single channel RGB LED and DMX lighting controller that has been specially designed
by musicians for musicians. Treat your lighting like an instrument by using MIDI to create custom
automated light shows. No additional hardware or software required. The LC-1X seamlessly
integrates with any existing hardware or software set-up. Just plug and play to begin elevating your
performances with synchronized lighting.
The LC-1X is controlled using 3 MIDI notes, which represent 1 RGB channel. An individual RGB colour
is designated to a specific MIDI note. MIDI velocity is used to control the brightness/intensity of RGB
colours. By combining MIDI notes within an RGB channel group and adjusting their velocities, you
can create an array of colours within the RGB colour spectrum.
For your own safety, please read this manual to learn how to safely
use, store and maintain the LC-1X prior to use.
