BOOMLIGHTS LC-1X - MIDI Note DIP Switch Table

Page 9 of 13
It is important to note that any changes to the DIP switches must be done while the unit is powered
off, as the unit only checks the DIP switch settings during start-up.
2.5.2 MIDI Note DIP Switch Table
Note
Octave
Number
Binary
Note
Octave
Number
Binary
C
-2
0
0000000
C
1
36
0100100
C#
-2
1
0000001
C#
1
37
0100101
D
-2
2
0000010
D
1
38
0100110
D#
-2
3
0000011
D#
1
39
0100111
E
-2
4
0000100
E
1
40
0101000
F
-2
5
0000101
F
1
41
0101001
F#
-2
6
0000110
F#
1
42
0101010
G
-2
7
0000111
G
1
43
0101011
G#
-2
8
0001000
G#
1
44
0101100
A
-2
9
0001001
A
1
45
0101101
A#
-2
10
0001010
A#
1
46
0101110
B
-2
11
0001011
B
1
47
0101111
C
-1
12
0001100
C
2
48
0110000
C#
-1
13
0001101
C#
2
49
0110001
D
-1
14
0001110
D
2
50
0110010
D#
-1
15
0001111
D#
2
51
0110011
E
-1
16
0010000
E
2
52
0110100
F
-1
17
0010001
F
2
53
0110101
F#
-1
18
0010010
F#
2
54
0110110
G
-1
19
0010011
G
2
55
0110111
G#
-1
20
0010100
G#
2
56
0111000
A
-1
21
0010101
A
2
57
0111001
A#
-1
22
0010110
A#
2
58
0111010
B
-1
23
0010111
B
2
59
0111011
C
0
24
0011000
C
3
60
0111100
C#
0
25
0011001
C#
3
61
0111101
D
0
26
0011010
D
3
62
0111110
D#
0
27
0011011
D#
3
63
0111111
E
0
28
0011100
E
3
64
1000000
F
0
29
0011101
F
3
65
1000001
F#
0
30
0011110
F#
3
66
1000010
G
0
31
0011111
G
3
67
1000011
G#
0
32
0100000
G#
3
68
1000100
A
0
33
0100001
A
3
69
1000101
A#
0
34
0100010
A#
3
70
1000110
B
0
35
0100011
B
3
71
1000111
