the dashboard. This strap also helps ensure proper electrical grounding of the unit.
Note to install the short threading terminal of the mounting bolt to the back of the unit and the
other long threading terminal to the dashboard.
10. Reconnect the cable to the vehicle battery’s negative (-) terminal. Then replace the outer trim
ring and install the unit’s front panel (see the steps of “installing the front panel”).
Removing the unit
1. Make sure the ignition is turned off, then disconnect the cable from the vehicle battery’s
negative (-) terminal.
2. Remove the metal strap attached the back of the unit (if attached).
3. Press the release button to remove the front panel.
4. Lift the top of the outer trim ring then pull it out to remove it.
5. Insert both of the supplied keys into the slots at the middle left and right sides of the unit, then
pull the unit out of the dashboard.
