BORETTI CFBG902AN - Lubrication of the Gas Taps

228
LUBRICATION OF THE GAS TAPS
In case of difficulty in the gas taps operation, call Service.
IMPORTANT
All intervention regarding installation maintenance of the appliance must be fulfilled with
original factory parts.
The manufacturer declines any liability resulting from the non-compliance of this obligation.
AIR VENT NECESSARY FOR GAS COMBUSTION = (2 m
3
/h x kW)
BURNERS Air necessary for combustion [m
3
/h]
Auxiliary (A) 2,00
Semi-rapid (SR) 3,50
Rapid (R) 6,00
Dual (D)
inner crown 1,60
outer crown 8,00
TABLE FOR THE CHOICE OF THE INJECTORS -
Cat: II 2EK3B/P
NL
TABLE FOR THE CHOICE OF THE INJECTORS -
Cat: II 2E+ 3+
FR
BE
G30/G31
30/30 mbar
G20
20 mbar
G25.3
25 mbar
BURNERS
Nominal
Power
[Hs - kW]
Reduced
Power
[Hs - kW]
Ø injector
[1/100 mm]
Ø injector
[1/100 mm]
Ø injector
[1/100 mm]
Auxiliary (A) 1,00 0,30 50 77 80
Semi-rapid (SR) 1,75 0,45 66 101 102
Rapid (R) 3,00 0,75 87 129 132
Dual (D)
inner
crown
0,80 (*) 0,35 (*)
46
(no.1 central)
70
(no.1 central)
71
(no.1 central)
outer
crowns
4,00(**) 1,90 (**)
65
(no.2 outer)
99
(no.2 outer)
100 T2
(no.2 outer)
(*) Power calculated with inner crown operating.
(**) Power calculated with inner and outer crowns operating.
G30/G31
28-30/37 mbar
G20/G25
20/25 mbar
BURNERS
Nominal
Power
[Hs - kW]
Reduced
Power
[Hs - kW]
Ø injector
[1/100 mm]
Ø injector
[1/100 mm]
Auxiliary (A) 1,00 0,30 50 77
Semi-rapid (SR) 1,75 0,45 66 101
Rapid (R) 3,00 0,75 87 129
Dual (D)
inner crown 0,80 (*) 0,35 (*) 46 (no.1 central) 70 (no.1 central)
outer crowns 4,00(**) 1,90 (**) 65 (no.2 outer) 99 (no.2 outer)
